Static APEX code analysis with PMD


Coding standard are only as good as they are followed. One venerable tool to check source code is PMD. When you, like I did, wonder what acronym PMD represents, you will be disappointed. PMD supports the usual suspects like C, C++, C#, Fortran, Java, JavaScript, Go, Groovy, XML... as well as Apex and Visualforce.

The default ruleset for Apex contains 34 rules and are the ones also used by CodeClimate

PMD is a Java application and you have a number options to run it:

  • As a command line application
  • Using ANT or Maven
  • In your CI platform (using command line, ANT or Maven )
  • Linking your Github (or Gitlab, Bitbucket) repository to a service like CodeClimate

PMD supports a series of output formats like plain, csv, html (different flavours) and XML. When you understand XSLT, the XML format allows you to render whatever report you deem fit

That is what I did. My XSLT stylesheet first shows the summary (one could render that as a dashboard), then the list of rules applied in the run, grouped by domains, then the findings by rule and finally the findings per file. Here you go:

<?xml version="1.0" encoding="UTF-8"?>
<xsl:stylesheet xmlns:xsl="http://www.w3.org/1999/XSL/Transform"
    xmlns:xs="http://www.w3.org/2001/XMLSchema" exclude-result-prefixes="xs" version="2.0">

    <xsl:output method="html"/>

    <xsl:template match="/">
        <html xmlns="http://www.w3.org/1999/xhtml">
            <head>
                <title>
                    <xsl:value-of select="/pmd/@timestamp"/>
                </title>
                <style type="text/css">
                    html,
                    body,
                    td{
                        font-family: Verdana, Arial, Sans-serif;
                        font-size: small
                    }
                    .filename{
                        font-weight: bold
                    }
                    .lineno{
                        color: #999999
                    }
                    h1, h2 { border-bottom: 1px solid gray; text-align: center; background-color: #CCCCCC}
                    h3 {border-left: 5px solid red; padding-left: 5px;}
                    span.rule { font-weight: bold; padding: 0; margin: 0; display: block}
                    li.rule { border-top: 1px solid gray; margin-top: 15px; }
                    a {text-decoration : none}
                    a:hover {text-decoration : underline}
                </style>
            </head>
            <body>
                <a name="top"></a><h1>Apex PMD report</h1>
                <p style="text-align: right;"><xsl:value-of select="/pmd/@timestamp"/> - v<xsl:value-of select="/pmd/@version"/></p>
                <h3>Table of content</h3>
                <ol>
                    <li><a href="#summary">Summary</a></li>
                    <li><a href="#rules">Checked rules</a></li>
                    <li><a href="#domain">Finding by rule</a></li>
                    <li><a href="#files">Finding by file</a></li>
                </ol>
                <a name="summary"></a><h2>1. Summary</h2>
                <xsl:apply-templates select="/pmd" mode="summary"/>
                <a href="#top">back to top</a>
                <a name="rules"></a><h2>2. Rules checked</h2>
                <xsl:apply-templates select="/pmd" mode="rules"/>
                <a href="#top">back to top</a>
                <a name="domain"></a><h2>3. Details by Domain</h2>
                <xsl:apply-templates select="/pmd" mode="domain"/>
                <a href="#top">back to top</a>
                <a name="files"></a><h2>4. Details by file</h2>
                <ol>
                    <xsl:apply-templates select="/pmd/file"/>
                </ol>
                <a href="#top">back to top</a>
            </body>
        </html>
    </xsl:template>

    <xsl:template match="file">
        <li>
            <xsl:variable name="filename" select="tokenize(@name, '/')[last()]" />
            <xsl:element name="a">
            <xsl:attribute name="class">filename</xsl:attribute>
            <xsl:attribute name="name" select="$filename" />
                <xsl:value-of select="$filename"/>
            </xsl:element>
            <ol>
                <xsl:apply-templates select="violation"/>
            </ol>
        </li>
    </xsl:template>

    <xsl:template match="violation">
        <li>
            <xsl:value-of select="."/>
            <span class="lineno">(lines <xsl:value-of select="@beginline"/>-<xsl:value-of
                    select="@endline"/>)</span>
        </li>
    </xsl:template>

    <xsl:template match="pmd" mode="summary">
        <ul class="summary">
            <li>Rules checked: <xsl:value-of select="count(distinct-values(file/violation/@rule))" /></li>
            <li>Domains: <xsl:value-of select="distinct-values(file/violation/@ruleset)"/></li>
            <li>Apex files with issues: <xsl:value-of select="count(file)"/></li>
            <li>Number of finding: <xsl:value-of select="count(file/violation)" /></li>
            <xsl:for-each-group select="file/violation" group-by="@ruleset">
                <li> findings in domain <xsl:value-of select="current-grouping-key()"/>:
                    <xsl:value-of select="count(current-group())"/>
                </li>
            </xsl:for-each-group>
        </ul>
    </xsl:template>

    <xsl:template match="pmd" mode="domain">
        <xsl:for-each-group select="file/violation" group-by="@ruleset">
            <xsl:variable name="key" select="current-grouping-key()" />
            <h3><xsl:value-of select="$key"/></h3>
            <ol>
            <xsl:for-each-group select="current-group()" group-by="@rule">
                <xsl:variable name="keytwo" select="current-grouping-key()" />
                <li class="rule"><xsl:value-of select="$keytwo"/>: <xsl:value-of select="count(current-group())"/>
                    <p class="rule">like: <xsl:value-of select="current-group()[position()=1]"/></p>
                    <ol>
                        <xsl:for-each select="current-group()">
                            <xsl:variable name="sibcount" select="count(parent::node()/violation[@rule=$keytwo])" />
                            <xsl:if test="count(preceding-sibling::node()[@rule=$keytwo]) eq 0">
                                <xsl:variable name="filename" select="tokenize(../@name, '/')[last()]" />
                               <li>
                                    <xsl:element name="a">
                                        <xsl:attribute name="href">#<xsl:value-of select="$filename" /></xsl:attribute>
                                    <xsl:value-of select="$filename" />
                                    </xsl:element>
                                    : <xsl:value-of select="$sibcount" /> finding(s)
                                </li>
                            </xsl:if>
                        </xsl:for-each>
                    </ol>
                </li>
            </xsl:for-each-group>
            </ol>
        </xsl:for-each-group>
    </xsl:template>

    <xsl:template match="pmd" mode="rules">
        <xsl:for-each-group select="file/violation" group-by="@ruleset">
            <h3><xsl:value-of select="current-grouping-key()"/></h3>
            <ol>
                <xsl:for-each-group select="current-group()" group-by="@rule">
                    <li><xsl:value-of select="current-grouping-key()"/></li>
                </xsl:for-each-group>
            </ol>
        </xsl:for-each-group>
    </xsl:template>

</xsl:stylesheet>

As usual YMMV!
